LEARNING GSTARCAD 1 – BASIC

LEARNING GSTARCAD 1 – BASIC

The course offers foundational knowledge needed to create simple, annotated drawings and further prepares the learner to develop GstarCAD skills.

RM 300.00
300.0 MYR RM 300.00
RM 300.00
Last Update 09/10/2021
Completion Time 1 hour 41 minutes
Members 1032
    • Introduction
    • Training exercise files
  • 1. The GstarCAD Interface
    • 1. The application menu
    • 2. The ribbon and panels
    • 3. Dialog boxes and palettes
    • 4. The status bar
  • 2. Drawing Simple Geometry
    • 1. OSNAP (object snap) and OTRACK (object snap tracking)
    • 2. POLAR (polar tracking) and ORTHO (orthogonal mode)
    • 3. Lines, arcs, and circles
    • 4. Polylines, polygons, and splines
    • 5. Using ZOOM and PAN
  • 3. Annotating Simple Designs
    • 1. Text styles
    • 2_Single line text (TEXT) and multiline text (MTEXT)
    • 3. Dimension styles
    • 4. Placing dimensions
    • 5. Adding a simple table
  • 4. Communication Your Design Intent
    • 1. Creating a simple title block
    • 2. Defining your page setup
    • 3. Adding new layouts and scaled viewports
    • 4. Using annotative scaling
    • 5. Printing and plotting
    • 5-1 Configuring GstarCAD plot drivers
